第26卷第3期化學反應工程與工藝Vol 26. No 32010年6月Chemical Reaction Engineering and TechJune 2010文拿編號:1001-7631(2010)03-0193-0漿態床合成氣制二甲醚反應器數學模擬胡智力1劉殿華房鼎業1潘強2顏蜀雋2羅春桃(1.華東理工大學大型工業反應器工程教育部工程研充中心,化學工程聯合國家重點實驗室,上海2002372.神華寧煤集團煤化工公司研發中心,寧夏銀川750411)搞要:建立了包括液相返混和催化劑顆教沉降的合成氣一步法制二甲醚漿態床反應器的數學模型,模擬計算了空速、原料氣組成、反應溫度、反應壓力等反應條件對反應的影響,計算結果表明,CO轉化率和二甲醚的選擇性隨溫度增加、壓力增大而提高,在一定溫度、壓力條件下,CO轉化率隨空速增大而減小,合成氣含有一定量的CO2有利于CO轉化率增加關鵪詞:漿態床;食成氣;二甲:學橫型中圖分樊號;TQ018文獻標識碼:A合成氣二步法制二甲醚(DME)要經過合成氣制甲醇和甲醇脫水兩個步驟,流程較長,設備投資大,產品成本較高,目前國內外都在大力開展由合成氣一步法制二甲醚的研究。合成氣一步法制二甲醚是放熱反應,在固定床反應器中進行時反應熱不易移出,存在溫度控制難等缺點,若使用貧氫合成氣,則反應溫度高,催化劑易結炭,因此固定床中氣相一步法反應只能在轉化率較低情況下操作,大量的未反應合成氣必須循環,并使用富氫合成氣。漿態床中合成氣一步法制二甲醚是在三相體系中進行的,CO、H2和DME等為氣相,惰性溶劑為液相,懸浮于溶劑中的催化劑為固相。氣相CO和H2穿過液相油層到達懸浮的固體催化劑表面進行反應,由于液相的熱容大,液相一步法很易實現恒溫操作,而且催化劑顆粒表面為溶劑所包圍,結炭現象大為緩解,因而液相法可使用貧氫合成氣,適合我國以煤為原料制合成氣的現狀。鑒于三相漿態床在合成二甲醚中的熱力學、工藝條件及反應器等方面的優勢,國內外已將二甲醚的工業化研究集中于三相漿態床合成反應器上,漿態床合成氣制二甲醚是未來工業化二甲醚生產的技術發展趨勢口-3。本工作建立了年產10萬噸二甲醚漿態床反應器模型,在合成氣H2和CO體積比為1~2,反應壓力4~6MPa,溫度230~300℃條件下,模擬研究了反應條件對反應的影響,以期為工業反應器的設計提供依據。漿態床反應器數學模型合成氣一步法制二甲醚是一個復雜的反應體系,主要反應有:CO+2H,=CH3 OHCO2+3H2=CH,OH+H2O2CH,OH=CH, OCH,+H2O3C0+3H2=CH3 OCH,+CO22c0+4H,=CH, OCH,+H,OCO+H2 O=CO,+H2中國煤化工(6)收稿日期:2010-04-21;修訂日期:2010-05-23CNMHG作著簡介:胡智力(1986),男,碩士研究生;劉殿華(1970-),男,副教授,通訊聯系人,Emal;delia@ecust.eud.cn薔金項目:國家科技支撐計劃資助(2007BAAo8B04)194化學反應工程與工藝2010年6月根據相律計算得知該反應體系的獨立反應數為3,選取CO、CO2、 CH, OCH3為獨立組分,式(1)、(2)和(3)為獨立反應1.1模型假設數學模型假設:(1)氣相為平推流;(2)催化劑固體顆粒較小,液固之間的傳質阻力忽略不計;(3)反應在高壓下進行,反應器內總壓不變;(4)在高空速條件下,床層溫度均勻;(5)考慮催化劑的軸向分布,用固相沉降模型處理催化劑的床層分布。1.2數學模型考慮液相返混和催化劑顆粒沉降后的數學模型如下:klai(Ht-Cl. ), (j= H2, CO2, CO, CH,OH, H, O, DMED,rGi= H2, CO2, CO)-c-(,-c),0-c0,H0DNB邊界條件Cx=c,clxn-c,。z|2-013模型參數采用銅基催化劑和yAl2O甲醇脫水催化劑為雙功能催化劑所測定的動力學方程:對()(-K/元)4舞)角(-xrrp Ag expR)(-m式中各個An為實驗擬合的模型參數,K為平衡常數,f為各組分的逸度,采用 SHBWR狀態方程計算(。反應器模型中其它參數-12如下:(4),(2-1)A-cb,頁=(-),=1,U了,U=Dp=P)U. Dg9.6()01+0.019R}1Re- U,DRpt, Re.=U.dee, D, =2. 7U'D2結果與討論已有文獻報道工業化或即將工業化的一步法漿態床中國煤化工斤要模擬的原料氣組成H2CO為1~2,故采用文獻的中試數據為模型CNMHG模型進行模擬計算結果見表1。第26卷第3期胡智力等.漿態床合成氣制二甲醚反應器數學模擬表1反應器模擬計算數據與文獻值的比較Table. 1 The comparison of computational results with pllot plant dataH:/COT/CXoo,Err.%Computational results607.1表1結果表明,反應器模擬計算數據與文獻中試數據比較的相對誤差為7.1%,表明建立模型與參數選擇合理,能較好地模擬反應器實際狀況。2.1空速的影響在反應壓力5MPa,反應溫度250℃C條件下,模擬計算了空速對CO的轉化率的影響,結果見圖1?？梢钥吹?隨著空速的增大,CO的轉化率下降,這是因?yàn)殡S著空速的提高,反應物在反應器停留時間短,合成反應不能充分進行。雖然在低空速下,CO轉化率較大,但生產能力會降低,故要適當控制空速圖1空速對CO轉化率的影響圖2CO2含量對CO轉化率的影響Fig. 1 Effect of space velocity on CO conversionFig. 2 Effect of CO, concentration on CO conversion2.2原料氣組成的影響圖2所示為反應壓力5MPa,反應溫度250℃,H2/CO為2的條件下原料氣中CO2含量變化對CO轉化率的影響。結果表明,含有適量的CO2有利于二甲醚的合成,但原料中CO2含量過高,會造成后續分離過程的困難,增加分離成本。因此在實際生產中應綜合考慮CO2含量對生產的影響。2.3反應溫度的影響圖3和圖4所示的是在反應壓力5MPa,不同合成氣配比(H2/CO)條件下,溫度的變化對CO轉化率以及產物二甲醚選擇性的影響。由圖可知,隨著溫度的增加,CO轉化率提高,二甲醚選擇性提高。雖然反應體系是放熱的,但在反應條件下,反應未達到平衡狀態,反應受動力學控制,所以隨著溫度的升高,CO轉化率增大,DME的選擇性也增大。------“070中國煤化工CNMHG圖3反應溫度對cO轉化率的影響度對UEM彈性的影響Fig 3 Effect of temperature on CO conversionFig. 4 Effect of temperature on DME selectivity196化學反應工程與工藝2010年6月2.3反應壓力的影響圖5與圖6表示的是在反應溫度250℃,不同合成氣配比(H2/CO)條件下,壓力的變化對CO轉化率和二甲醚選擇性的影響?？梢钥吹?隨著壓力的增大,CO轉化率提高,二甲醚選擇性提高。因?yàn)楹铣蓺庵贫酌咽强傮w積減小的反應,增大壓力有利于反應進行。4.5505.5606P/ MPaP/ MPa圖5反應壓力對CO轉化率的影響6反應壓力對DEM選擇性的影響Fig 5 Effect of prCO conversionFig. 6 Effect of pressure on DME selectivity3結論建立了包括液相返混和催化劑顆粒沉降的合成氣一步法制二甲醚漿態床反應器的數學模型,通過對不同反應條件下漿態床合成氣制二甲醚的模擬計算,考察了反應條件對反應的影響,在工業反應器的設計中,在不影響催化劑及設備條件下,應適當提高反應溫度、壓力,原料氣中CO2的含量不易過大,宜控制在5%以內符號說明a—?dú)庖罕缺砻娣e,m2/m2反應器進口催化劑濃度,kg/m2反應器內沿床層高度催化劑濃度,kg/m3反應器內催化劑平均濃度,kg/m3氣相中j組分的濃度,kmol/m2液相中j組分的濃度,kmol/r催化劑顆粒粒徑,m液相軸向擴散系數,m2/sDR反應器內徑,m顆粒軸向擴散系數,m2/s重力加速度,m/s2氣體溶解度,kg/kg床層高度,m氣液傳質系數,m/s反應的平衡常數CO加氫反應速率,kmol/(kgm·b)CO2加氫反應速率,kmol( kKat.h二甲醚生成速率,kmol/(kgah)氣相的 Reynold數顆粒的 Reynold數溫度表觀氣速,m/s顆粒受阻沉降速度,m/s顆粒閆由沉降速度催化劑密度,kg/m3液相密度,kg/m3H中國煤化工參考文獻:NMHGI Moradi GR, Nazari M, Yaripour F. Statistical Analysis of the PerformLanyon unue. sperating Conditionsof LPDME Process. Chemical Engineering Journal, 2008, 140: 255-263第26卷第3期胡智力等.漿態床合成氣制二甲醚反應器數學模擬1972 Prasad P SS, Bae J W, Kang S H, et al Single-Step Synthesis of DME from Syngas on Cu-Zno-Al O/Zeolite BifunctionalCatalysts: The Superiority of Ferrierite over the Other Zeolites, Fuel Processing Technology, 2008, 89: 1281-12863 Chena P, Guptab P, Dudukovica M P, et aL Hydrodynamics of Slurry Bubble Column during Dimethyl Ether(DME) SynthesisGas-Liquid Recirculation Model and Radioactive Tracer Studies, Chemical Engineering Science, 2006, 61: 6553--65704趙玉龍,張碧江,煤液化中氣液固反應工程概況化學工程,1984,12(2):45~57Zhao Yulong, Zhang Bijiang. Gar Liquid-Solid Reaction Engineering in Liquefaction of Coal. Chemical Engineering, 1984, 12(2)45~575劉殿華,華鯡,房鼎業.固定床合成氣制二甲醚的本征動力學研究,天然氣化工,2007,32:18~22Liu Dianhua, Hua Xing, Fang Dingye. Intrinsic Kinetics of Dimethyl Ether Synthesis from Syngas in Fixed Bed Reactor. NaturalGas Chemical Industry, 2007. 321 18-226張海海,曹發海,劉殿華等.合成氣直接合成二甲嬖與甲醇的熱力學分析.華東理工大學學報,2007,27(2):198~201Zhang Haitao, Cao Fahai, Liu Dianhua, et aL Thermodynamic Analysis for Synthesis of Dimethyl Ether and Methanol fromSynthesis Gas. Journal of East China University of Science and Technology, 2007, 27(2): 198-2017郭天民.多元?dú)庖浩胶夂途s,北京:石油工業出版社,2002mith D N, Ruether JAlid Dynamics in a Sully Bubble Column, Chemical Engineering Science, 1985, 40(5)1 741-754宋懷俊,張海濤,應衛勇.H2、N2、CO和CO2在液體石蠟中的溶解度和傳質系數的研究.華東理T大學學報,200430(5)498~518Song Huaijun, Zhang Haitao, Ying Weiyong. Investigation on Solubility and Volumetric Mass Transfer Coefficient of Hi, N2, cOand CO in Liquid Paraffin. Journal of East China University of Science and Technology, 2004, 30(5): 498-51810宋懷俊,張海濤,應衛男.二甲醚在液體石蠟中的溶解度和體積傳質系數的研充,高校化學工程學報,2005,19(2);253~257Song Huaijun, Zhang Haitao, Ying Weiyong. Study on Solubility and Volumetric Mass Transfer Coefficient of Dimethyl EtherinLiquid Paraffin. Journal of Chemical Engineering of Chinese Universities, 2005, 19(2): 253-25711宋懷俊,張海濤,應衛勇等.甲醇、水蒸氣在液體石蠟中的溶解度和體積傳質系數的研究石油化工,2005,34(6);551~555Song Huaijun, Zhang Haitao, Ying Weiyong, et al. Solubilities and Volume Mass Transfer Coefficients of Methanol and Steam inLiquid Paraffin. Petrochemical Technology, 2005, 34(6) 551-5552秦惠芳,王世榮,丁百全等,醫用液體石蠟的物性數據測定及估算.天然氣化亡,199,24(3):56~58Qin Huifang, Wang Shirong, Ding Baiquan, et al. Determination and Estinmtion of Physical Property Data for Liquid Paraffin.Natural Gas Chemical Industry, 1999, 24 (3)1 56-513黎漢生,任飛,王金福.漿態床一步法二甲醚產業化技術開發研究進展.化工進展,2004,23(9):921~924Li Hansheng, Ren Fei, Wang Jinfu. Progress in Development of Direct Mass Production Technique of Dimethyl Ether fromSynthesis Gas in a Slurry Reactor. Chemical Industry And Engineering Progress, 2004, 23 (9)14 OKawa T, Inoue N, Shikada T, et al Direct Dimethyl Ether Synthesis. Joumal of Natural Gas Chemistry, 2003, 12(4): 219-227Mathematical Simulation for Synthesis of Dimethyl Ether from Syngasin a Slurry Bubble Column ReactorHu Zhili Liu Dianhua Fang Dingye Pan Qiang Yan Shujun Luo Chuntao(1. Engineering Research Center of Large Scale Reactor Engineering and Technology of Ministry of Educationate Key Laboratory of Chemical Engineering, East China University of Science and Technology, Shanghai 200237, China2. Research and Development Center, Shenhua Ningxia Coal Industry Group Co Ltd, Yinchuan 750411, ChinaAbstract: A mathematical model for one step synthesis of dimethyl ether from syngas in a slurrybubble column reactor was developed, considering the influence of inert carrier backmixing and theinfluence of catalyst grain sedimentation. The effects of the space velocity, feed gas compositiontemperature and pressure were discussed. The results showed that CO conversion and DME selectivityincreased with the increase of temperature and pressure.rtain temperature and pressureconditions, the conversion of co decreased with the incre中國煤化工; th a certainamount of CO, was benefit to increasing of CO conversiCNMHGKey words: slurry reactor; syngas; dimethyl ether; mathematical model
